Hamm HD 14i TT
| Make | Hamm |
| Model | HD 14i TT |
| Type | Series HD CompactLine |
How can we help?
Description
-
Simple, intuitive and language-neutral control
-
Simple transport, simple loading
-
Ergonomic driver platform
-
Excellent view of tires, machine and construction site
-
Compact dimensions
Specifications
- BASIC DATA - Description: Tandem roller with two sets of tires
- BASIC DATA - Exhaust emissions category: EU Stage V / EPA Tier 4
- BASIC DATA - Name: HD 14i TT
- BASIC DATA - Series: HD CompactLine
- BASIC DATA - Series: H264
- DIESEL ENGINE - Exhaust gas after-treatment: DOC-DPF
- DIESEL ENGINE - Number of cylinders: 4
- DIESEL ENGINE - Power ISO 14396, HP: 50.9 HP
- DIESEL ENGINE - Power SAE J1995, HP: 50.1 hp
- DIESEL ENGINE - Power SAE J1995, kW: 37.4 kW
- DIESEL ENGINE - Power SAE J1995, rpm: 2,700 RPM
- DIESEL ENGINE - Type: V2403-CR
- DRIVE - Climbing ability: 40 %
- DRIVE - Speed, infinitely variable: 0,0-6,2
- MACHINE DIMENSIONS - Ground clearance, center: 12 in
- MACHINE DIMENSIONS - Height, loading, min.: 71.7 in
- MACHINE DIMENSIONS - Total height with cab: 107.1 in
- MACHINE DIMENSIONS - Total height with ROPS: 102 in
- MACHINE DIMENSIONS - Total length: 116.7 in
- MACHINE DIMENSIONS - Total width: 51 in
- MACHINE DIMENSIONS - Turning radius, inside: 102.4 in
- MACHINE DIMENSIONS - Wheelbase: 76.8 in
- SOUND LEVEL - Acoustic power LW(A), measured: 100 db(A)
- SOUND LEVEL - Acoustic power LW(A), sticker: 101
- SPRINKLER SYSTEM - Water sprinkler, type: Pressure
- SPRINKLER SYSTEM - Water tank, capacity: 68.7 gpm
- STEERING - Oscillation angle +/-: 8 °
- STEERING - Steering, type: Articulated steering
- TANK CAPACITY/FILL CAPACITY - Additive tank, capacity: 4.8 gpm
- TANK CAPACITY/FILL CAPACITY - Fuel tank, capacity: 19.3 gpm
- WEIGHTS - Axle load, front: 3,704 lbs
- WEIGHTS - Axle load, rear: 4,112 lbs
- WEIGHTS - Basic weight no cab, without ROPS: 7,067 lbs
- WEIGHTS - French classific., data/class: 5,6/PLO
- WEIGHTS - Operating weight with cab: 8,478 lbs
- WEIGHTS - Operating weight with ROPS: 7,817 lbs
- WEIGHTS - Operating weight, max.: 9,702 lbs
- WEIGHTS - Wheel load per tire, front: 1,235 lbs
- WEIGHTS - Wheel load per tire, rear: 1,028 lbs
- WHEEL DIMENSIONS - Number of tires, front: 3
- WHEEL DIMENSIONS - Tire size, front: 10.5
- WHEEL DIMENSIONS - Tire size, rear: 80-16
- WHEEL DIMENSIONS - Width over tires, front: 44.4 in
- WHEEL DIMENSIONS - Width over tires, rear: 50.2 in
